Model No: 8*19S+NF-6mm
Lifting Rope Wire 8*19S+NF-6mm For Tokyo | 6mm Wire Rope
Besides the 8*19S+NF-6mm for Tokyo, Potensi also have Tokyo elevator steel wire rope such as the 8*19S+NF-8mm, 8*19S+NF-10mm, 8*19S+NF-12mm, 8*19S+NF-14mm 8*19S+NF-16mm, 8*19W+NF-8mm, 8*19W+NF-10mm, 6*25Fi+NF-8mm, 8*25Fi+NF-8mm, 8*25Fi+NF-10mm.
Quantity :
add to cart
Contact Now
-Why Choose Potensi-
Tokyo wire rope 8*19S+NF-6mm model provides superior flexibility. Potensi is one of the elevator wire rope manufacturers, provides very cheap steel wire rope for elevators price. Potensi 6mm wire rope guarantee safety and reliability. Besides the 8*19S+NF-6mm for Tokyo, Potensi also have Tokyo elevator steel rope such as the 8*19S+NF-6mm,8*19S+NF-8mm, 8*19S+NF-10mm,8*19S+NF-12mm,8*19S+NF-13mm,8*19S+NF-14mm, 8*19S+NF-16mm, 8*19W+NF-8mm, 8*19W+NF-10mm, 6*25Fi+NF-8mm,8*25Fi+NF-8mm, 8*25Fi+NF-10mm.
Tykyo lifting rope wires are with enough stocks and ready to ship at any time. Not only 6mm wire rope can be guaranteened 100% original and 100% new, but also we promise all parts Potensi supplied are not secondhand or refurbished. Potensi supply all types of lifting rope wires. Potensi is able to supply more 99% muti-brand elevator spare parts with competive price with 21 years experience in China elevator industry. POTENSI looks forward to working with you in near future.
-Tokyo Steel Wire Rope 8*19S+NF Parameters-
| Rope diameter (mm) | Outer wire diameter (mm) | Sectional area | Breaking force(kN) | (Reference)Rough calculation Unit mass | ||
| Galvanized | Bright | |||||
| (mm) | Grade G | Grade A | Grade B | (kg/m) | ||
| 8 | 0.53 | 23.1 | 26.0 | 30.8 | 32.8 | 0.220 |
| 10 | 0.66 | 36.5 | 40.6 | 48.1 | 51.3 | 0.343 |
| 11.2 | 0.74 | 45.8 | 51.0 | 60.3 | 64.3 | 0.430 |
| 12 | 0.80 | 52.6 | 58.5 | 69.2 | 73.8 | 0.494 |
| 12.5 | 0.83 | 58.0 | 63.5 | 75.1 | 80.1 | 0.536 |
| 14 | 0.93 | 72.6 | 79.6 | 94.3 | 100 | 0.672 |
| 16 | 1.06 | 93.5 | 104 | 123 | 131 | 0.878 |
| 18 | 1.19 | 118 | 132 | 156 | 166 | 1.11 |
| 20 | 1.32 | 146 | 162 | 192 | 205 | 1.37 |
| 22.4 | 1.47 | 183 | 204 | 241 | 257 | 1.72 |
| 25 | 1.65 | 230 | 254 | 301 | 320 | 2.14 |
