Model No: MCK100 380V
Gearless Traction Machine MCK100 For MONADRIVE | MONADRIVE Traction Machine
Besides the MCK100, Potensi also have MONADRIVE traction machines such as the MCK200, MONA180, MONA180A, MONA200, MONA200A, MONA320, MONA320A, MGD65, MGD65L, MGD87, MGD100, MCB100, MCB200.
Quantity :
-Why Choose Potensi-
MONADRIVE elevator traction motors are manufactured under ISO 9001:2000 standards and carry full CE certification. MONADRIVE elevator traction machines deliver reliable, smooth operation, strong load capacity, and high energy efficiency. Monadrive MCK100 traction machines provided by POTENSI utilizes permanent magnet synchronous technology to significantly reduce elevator energy consumption. Available in multiple load specifications of 320kg, 450kg, and 630kg, MONADRIVE MCK100 permanent magnet synchronous gearless traction machine covers various application scenarios such as residential and small commercial buildings.
MONADRIVE elevator traction machine has compact design and low maintenance requirements. Potensi offers MONADRIVE permanent magnet synchronous gearless traction machines are available in the following specifications: MCK100, MCK200, MCK300, MCK500, MONA150A, MONA150B, MONA180, MONA180A, MONA180B, MONA200, MONA200A, MONA200D,MONA200AD, MONA320, MONA320A, MGD65, MGD65L, MGD87, MGD100, MCB100, MCB200, MQ230, MQ270, MQ290, and are CE certified.
MONADRIVE elevator gearless traction machines are with enough stocks and ready to ship at any time. Not only MONADRIVE MCK100 can be guaranteened 100% original and 100% new, but also we promise all parts Potensi supplied are not secondhand or refurbished. Potensi supply all types of elevator gearless traction machines and geared traction machines. Potensi is able to supply more 99% muti-brand elevator spare parts with competive price with 21 years experience in China elevator industry. Potensi looks forward to working with you in near future.
-MONADRIVE Traction Machine MCK100 Parameters-
| Type | Spec. | Elv.Load | Elv.Speed | Sheave Dia | Sheave Groove | Current | Power | Speed | Freg. | Torque | Poles | β Angle | ||
| kg | m/s | mm | A | kw | r/min | Hz | Nm | mm | mm | ° | ||||
| MCK100 | 320-0.5 | 320 | 0.5 | 320 | 3×φ8×12 | 3 | 1.1 | 60 | 10.0 | 180 | 20 | 251 | 52 | 95 |
| MCK100 | 320-0.63 | 320 | 0.63 | 320 | 3×φ8×12 | 3 | 1.4 | 75 | 12.5 | 180 | 20 | 251 | 52 | |
| MCK100 | 320-1.0 | 320 | 1.0 | 320 | 3×φ8×12 | 5 | 2.2 | 119 | 19.8 | 180 | 20 | 251 | 52 | |
| MCK100 | 320-1.5 | 320 | 1.5 | 320 | 3×8×12 | 8 | 3.4 | 179 | 29.8 | 180 | 20 | 251 | 52 | |
| MCK100 | 450-0.5 | 450 | 0.5 | 320 | 4×8×12 | 5 | 1.5 | 60 | 10.0 | 240 | 20 | 251 | 52 | |
| MCK100 | 450-0.63 | 450 | 0.63 | 320 | 4×φ8×12 | 5 | 1.9 | 75 | 12.5 | 240 | 20 | 251 | 52 | |
| MCK100 | 450-1.0 | 450 | 1.0 | 320 | 4×φ8×12 | 7 | 3.0 | 119 | 19.8 | 240 | 20 | 251 | 52 | |
| MCK100 | 450-1.5 | 450 | 1.5 | 320 | 4×φ8×12 | 11 | 4.5 | 179 | 29.8 | 240 | 20 | 251 | 52 | |
| MCK100 | 450-1.75 | 450 | 1.75 | 320 | 4×φ8×12 | 11 | 5.3 | 209 | 34.8 | 240 | 20 | 251 | 52 | |
| MCK100 | 630-0.5 | 630 | 0.5 | 320 | 5×φ8×12 | 7 | 2.1 | 60 | 10.0 | 340 | 20 | 261 | 57 | |
| MCK100 | 630-0.63 | 630 | 0.63 | 320 | 5×8×12 | 7 | 2.7 | 75 | 12.5 | 340 | 20 | 261 | 57 | |
| MCK100 | 630-1.0 | 630 | 1.0 | 320 | 5×φ8×12 | 10 | 4.2 | 119 | 19.8 | 340 | 20 | 261 | 57 | |
| MCK100 | 630-1.5 | 630 | 1.50 | 320 | 5×φ8×12 | 16 | 6.4 | 179 | 29.8 | 340 | 20 | 261 | 57 | |
| MCK100 | 630-1.6 | 630 | 1.6 | 320 | 5×φ8×12 | 16 | 6.8 | 191 | 31.8 | 340 | 20 | 261 | 57 | |
| MCK100 | 630-1.75 | 630 | 1.75 | 320 | 5×φ8×12 | 16 | 7.4 | 209 | 34.8 | 340 | 20 | 261 | 57 |
